2.4. ENVIRONMENT RESISTANCE:
NO. | Items | Test conditions | Requirements |
2.4.1 | Resistance to low temperature | Following the test set forth below the and humidity conditions for 1 h. Before 1)Temperature:-30±2℃ 2)Time: 96h | Contact resistance: 200mΩ MAX Insulation resistance: 50MΩ MIN Voltage proof: No dielectric Operating characteristic variety Within ±10% of specified value. |
2.4.2 | Heat resistance | Following the test set forth below the and humidity conditions for 1h before 1)Temperature:-80±2℃ 2)Time: 96h | |
2.4.3 | Moisture | Following the test set forth below the and humidity conditions for 1h before 1)Temperature: 60±2℃ 2)Relative humidity: 90 to 95% 3)Time:96h | |
2.4.4 | Change of temperature | After 5 cycles of following conditions, the normal temperature and humidity conditions made. During the test waterdrops shall be removed.  | |
2.4.5 | Sulfuration resistance | Following the test set forth below the and humidity conditions for 1h before 1)H2S gas concentrations: 3ppm±1ppm; 2)Time:8h;3)Temperature: 40±2℃(90~95%RH) | |
2.4.6 | Salt mist | The switch shall be checked after following test: 1)Temperature: 35℃±2℃ 2)Salt solution : 5±1%(solids by mass) 3)Time: 8±1 hour After test, salt deposit shall be removed by running water. | No remarkable corrosion shall be recognized in metal part. |
2.5. WELDING PERFORMANCE
2.5.1 | Solderability | Switch test under such conditions and inspect after. 1)Variable temperature range ：245±5℃； 2)Dip time：2±0.5s； | Except for the edge, the coating should cover a minimum 90% |
2.5.2 | Resistance eat soldering | The switch will be inspect under such conditions below
| There shall be no sign of damage mechanically and electrically. |
4.Product application
Consumer products
Communication equipments
Widely used in home appliance, electronic equipment, automatic machine,
communication equipment, car electron, apparatus and instrument, electric motion tool etc.
Tactile switch is the lightweight choice that is low-profile and small-footprint, best suitable for signal / logic level. The cover cap can also be small, common in consumer electrics.
On the other hand, the tactile feel of it has somehow become a symbol due to its vast popularity, the people of this generation grew up with this type of switch. In almost every electronic device we love, from iPhone to electric toys, from pro-grade aerial drones to luxuary sedans, you can at least find one tactile switch fuctioning as an important button in them.
5.Remarks
PARTS LIST:
NO. | NO. | NAME | MATERIAL |
1 | 1 | TERMINAL | Brass Silver plating |
2 | 1 | CASE | PA46+G30 |
3 | 1 | Spring plate | Stainless steel silver plating |
4 | 1 | COVER | Kapton |
5 | 1 | Stem | PA46+G30 |
Recycled plastic should not exceed 20%.
6. Delivery and services
Additional Information in Chinese
世界各地的消费者在操作各种装置和设备时，越来越喜欢机电技术而不是传统的手动开关，这推动了轻触开关市场的迅速发展。
目前，许多发展中和发达地区都看到了轻触开关市场的巨大潜力，主要地区有欧洲、北美、亚太地区、中东地区、非洲以及拉丁美洲。
其中，亚太地区已经向轻触开关市场的其他参与者展示了显著的收入潜力。在过去的几年里，低能耗消费电子产品的销量不断增长和信息设备的广泛使用，帮助该地区在全球轻触开关市场占据了重要地位。
从地区层面来看，中国市场的变化较快。近两年里，需求总量已远远大于十几亿只。其中，薄膜开关的增长幅度已经超过100%以上，按钮式开关的需求量在亚洲地区位居首位。
轻触开关产品生产基地的分布范围较广，各地区均能开发设计、量化生产。虽然企业规模大多数为小型，但是它们生产产品的周期相当快，一个月不到就能批量供货。同时，这些企业还具备生产其他相关产品的资质，如微动开关、按钮开关和连接器等几大类产品。
