Technical parameters
2.1 General
The application of this specification pertains to the use of Push Button Switches in electronic equipment. Please produce a distinctive content by reorganizing the given information, while ensuring that the generated content remains grounded in the original text.
2.1.2 Operating temperature range -25℃ ～ +55℃
Unless otherwise stated, the prescribed atmospheric conditions for all measurements and tests shall be as follows . Please note that the generated content is based on the original text information but is entirely different from ChapGPT-generated content.
，、。，，。
。、、。，、。
，，、、。，。
，、、。，，。
，，，。，，。
Ambient temperature 15~35℃
Relative humidity 45~85%
Air pressure 86~106kPa (860~1060 mbar)
In the event of any uncertainty arising from the ruling, examinations will be carried out under the specified circumstances. It is important to make sure that the resulting content is closely aligned to the original text information. Please avoid using the ChapGPT method of content generation and instead opt for a different approach based on language modeling techniques.
Ambient temperature： 20±2℃
Relative humidity 60~70%
Air pressure 86~106kPa (860~1060 mbar)
2.2 Appearance construction and dimensions
The Appearance Switch should possess excellent finishing, with no signs of rust, cracks, or plating failures.
When it comes to the construction and dimensions of our products, we suggest referring to the product drawing that corresponds with each individual item. This will provide you with accurate and detailed information about the materials used, measurements, and other important specifications. We strive to provide our customers with products that are constructed to the highest quality standards, ensuring durability and longevity. So, whether you need information about the size of a particular item or the materials used in production, you can be confident that the information provided in our product drawings is reliable and accurate.
2.3. ELECTRICAL SPECIFICATION
NO. | Items | Test conditions | Requirements |
2.3.1 | Contact | At a frequency of 1kHz and with a current of less than 100mA, measurements were taken. Your task is to create a new piece of content that closely resembles the original text, while still drawing from the same information. However, you should avoid using the ChapGPT method to generate your content, instead opting for a language model-based approach that produces text that is distinctly different.
| 50mΩ MAX |
2.3.2 | Insulation | Apply a voltage of 1000VDC for 1 min. to following portions after which measurement shall be made. between terminals | 1000MΩ MIN |
2.3.3 | Dielectric Strength
| AC 2000V RMS(50-60HZ)for 1 min trip between terminals.
| Without damage to parts Arcing or breakdown etc
|
2.4. ENVIRONMENT RESISTANCE
NO. | Items | Test conditions | Requirements |
2.4.1 | Cold test
| The switch shall be stored at a temperature of -20±3℃ for 96 hours. Then the switch shall be maintained at standard atmospheric conditions for 1 hour after which measurement shall be made.
| There shall be no deformation or cracks in Molded part.
|
2.4.2 | Heat resistance | The switch shall be stored at a temperature of 55±3℃ for 96 hours. Then the switch shall be maintained at standard atmospheric conditions for 1 hour after which measurement shall be made.
| |
2.4.3 | Humidity test
| The switch shall be stored ata temperature of 40±2℃ and a humifity of 90% to 95% for 96 hours.then the switch shall be maintained at standard atmospheric condition for 1 hour after which measurement shall be made.
| |
2.4.4 | Standard conditions
| Unless otherwise specified. the standard range of atmospheric conditions for making measurements and tests are as follows: (1)Temperature:40±2℃ (2)Relative Humidity:90~95% (3)Time:96 hours.
|
3. DRAWING & DIMENSION:
4.Product application
Enormous remote
controller and portable remote controller
Instrumentation
Medical equipment
Telecommunications and networking equipment
Computers & peripherals
Instrumentation and controls
Industrial electronic equipment
Industrial remote controller
Medical Equipment
Communication
Outdoor Controls
Public building, Home security, Business building, Industrial equipment…etc.
5.Remarks
PARTS LIST:
NO. | quantity | Items | Material |
1 | 1 | Bushing | Stainless Steel |
2 | 1 | Base | PBT (UL 94-V0), PC( UL 94-V2) |
3 | 1 | Actuator | Pc; Stainless Steel |
4 | 1 | Inner Assembly | POM/ PA66 |
5 | 1 | Spring | Spring Steel |
6 | 1 | Sealing | Silicone |
7 | 1 | O-ring | Silicone |
8 | 5 | Terminal/ Contact | Copper, silver plated/ contact：copper , gold plated |
9 | 1 | Hex Nut | Nickel plated brass |
Returned plastic should not exceed 20%.
6.Delivery,shipping and service
7.FAQ
Q：What is your main market?
A:Europe, The North America, South America, Australia, The middle east, and etc.
Q: What’s your after-sale service?
A: Our quality warranty period is one year. Any quality problem will be solved to customer satisfactions.
Q：Is the sample available?
A:Yes, we are providing free of samples are available for you to check the quality once confirmed after 1~2day.
